CNC Jig Grinding Machine (Detail)
Home/About Pacific Jig Grinding Services/Capabilities Parts Gallery Contact Us


Parts Gallery


Mouseover image for description. Click image to enlarge
Jig Grinding - Radii being ground on inspection gage General tolerance of +/- .0002 on size and location was held on walls of blind pockets and thru holes of mold base Utilizing a CBN super abrasive on a carbide mandrel for rigidity cuts grind time in half Indicating deltronic pin to establish roll dimension on a fixture
The programmable reciprocating zones were used to grind the 54 holes in these 2 plates that are at different heights on the jig grinding machine Chop jig grinding on outside profile Inside form (radius and angle) for this sleeve was dressed on a resin bonded borazon using CNC jig grinder
Jig Grinding Machine
